| Nominal Pressure | 12000KN |
| hot press platen size | 4200(L)*1370(W)*65mm(H) |
| Feeding mode | double input and double output |
| Plywood size(mm) | 12302700mm,12302850mm,12303000mm,12303050mm,1230*3900mm |
| Max. opening space | 80mm |
| Number of layers | 15 layers |
| Main oil cylinder of press | Φ2601350mm8PCS |
| Press lifting cylinder | Φ2601350mm2PCS |
| Working stroke(mm) | 1200mm |
| Working press(kg/cm2) | 21kg/cm2 |
| Closing speed(M/min) | 3.6M/min |
| Overall size(mm) | 5650mm(L)*1405mm(W)*4750mm(H) |
| Hydraulic station | Fully sealed dust-free design |
| Total weight | 90T |
| Plywood size | 12302700mm,12302850mm,12303000mm,12303050mm,1230*3900mm |
| Opening | 80mm |
| Number of layers | 15 layers |
| Diameter and number of lifting cylinder(mm) | Φ902300mm2PCS |
| Working stroke(mm) | 2150mm |
| Lifting speed | 3.6M/min |
| Overall size(mm) | 4220mm(L)*2020mm(W)*5500mm(H) |
| Driving feeding | double hydraulic motor |
| Total weight(T) | 11T |
